2.4-Inch QVGA IPS TFT-LCD Display RGB interface

This source-tracked comparison record covers a 2.4" IPS-TFT module. Its imagery and listed values support initial engineering review; availability, model ownership and the final specification require Fuzheng confirmation before quotation or sample evaluation.

IPS-TFT
Rectangular
8080 series 16-bit parallel
8080/6800
240 (RGB) x 320

Screen Size: 2.4"
Resolution: 240 (RGB) x 320
Technology: IPS-TFT
Shape: Rectangular
Interface: 8080 series 16-bit parallel
Brightness: 500cd/m2

Request a Quote Request a Sample

View Full Specifications

Discuss this module with an engineer

Comparison candidate: specifications remain available for review; external product imagery is withheld until Fuzheng supplies or approves replacement media.

Technical specifications

Reference values are displayed for comparison and require confirmation before quotation.

Published specifications for 2.4-Inch QVGA IPS TFT-LCD Display RGB interface
Specification	Published value	Review status
Screen Size	2.4"	Confirm before quotation
Resolution	240 (RGB) x 320	Confirm before quotation
Technology	IPS-TFT	Confirm before quotation
Shape	Rectangular	Confirm before quotation
Interface	8080 series 16-bit parallel	Confirm before quotation
Brightness	500cd/m2	Confirm before quotation
Viewing Angle	All round - IPS	Confirm before quotation
Module Dimensions	42.4 x 58.8 x 3.3 mm	Confirm before quotation
Aspect Ratio	4:3	Confirm before quotation

Mechanical fit

Screen Size: 2.4"
Shape: Rectangular
Module Dimensions: 42.4 x 58.8 x 3.3 mm

Allow space for the FPC, connector, cover lens and mounting. Use an approved, version-matched drawing before fixing the enclosure.

Review drawing availability →

Interface & integration

Connection information for 10297
Parameter	Source value
Interface	8080 series 16-bit parallel

Confirm pin numbering, supply levels, controller revision and initialization before connecting power. Source tables are references, not a substitute for an approved electrical specification.

Format and image area

Published screen size: 2.4". Resolution: 240 (RGB) x 320. Shape: Rectangular. Module dimensions: 42.4 x 58.8 x 3.3 mm.

Electrical connection

Published interface: 8080 series 16-bit parallel.

Optical and front assembly

Brightness: 500cd/m2. Viewing angle: All round - IPS.

Drawings & technical documents

Reference files from this product record, retained at their available source resolution.

Request the matching mechanical drawing

No separate mechanical drawing is verified in this record. Send your enclosure limits and the selected product reference; request the approved outline and FPC drawing before tooling.

Request drawing & datasheet

Match the module to your application

Use the published values as a starting point, then document the host electronics, enclosure, user interface and operating environment before requesting a sample.

Send product requirements

Confirm availability and the final electrical, optical and mechanical specification before design-in.
Review interface, connector and FPC alignment against the host electronics.
Discuss touch panel and cover lens requirements where the product design needs a front assembly.
Confirm outline, active area, mounting constraints and environmental requirements before sample approval.

Product questions

Specifications, documents and sample planning for 10297.

What are the published specifications for 10297?

10297 currently publishes Screen Size: 2.4"; Resolution: 240 (RGB) x 320; Technology: IPS-TFT; Shape: Rectangular; Interface: 8080 series 16-bit parallel; Brightness: 500cd/m2. Confirm the final drawing and pin assignment against the supplied sample before design-in.

What should I include in an inquiry for this display?

Include the product name or model, target size and resolution, host interface, touch and cover-lens requirements, brightness and environment, quantity and current project stage.

Can I request a sample for evaluation?

Use the sample request action and share the intended electrical and mechanical integration requirements so the evaluation scope can be discussed around this exact record.

Can interface, touch or mechanical requirements be discussed?

Yes. Send the host interface, connector or FPC constraints, touch and cover-lens needs, outline limits and environmental targets for an engineering review. No unpublished capability is assumed on this page.
