RS60 Rugged Handheld Terminal
Honeywell N6603 Scanning Engine | 5.5″ IPS | Qualcomm Octa‑Core | Android 10 | 5000mAh Battery
The RS60 handheld terminal is built for fast, accurate barcode capture. Powered by the Honeywell N6603 scanning engine, it reads virtually all 1D/2D barcodes with precision down to 3mil. Combined with a 5.5‑inch IPS HD+ display, Qualcomm octa‑core processor, and a 5000mAh detachable battery, the RS60 delivers reliable performance for inventory management, retail operations, and logistics applications. Optional NFC adds contactless tag reading capability.
Why Choose RS60?
Premium Honeywell Scanning Engine
Equipped with the Honeywell N6603 – a high‑performance 2D imager. Reads codes including Code 128, Code 39, UPC/EAN, Code 93, Interleaved 2 of 5, PDF417, Data Matrix, QR Code, Aztec, MaxiCode, and more. Accuracy ≥3mil ensures even small or damaged barcodes are captured reliably.Solid Performance
Powered by the Qualcomm SDM450 octa‑core 1.8GHz processor with Android 10 and 4GB RAM + 64GB ROM (expandable via TF to 128GB). Smooth day‑to‑day operation for data‑intensive tasks.Compact & Ergonomic
Dimensions: 170 × 80(73) × 23 mm | Weight: <420g (including battery) – comfortable for extended shifts.Long‑Lasting Detachable Battery
3.8V / 5000mAh removable battery – swap batteries without downtime.Clear 5.5″ Display
5.5‑inch IPS HD+ screen (720×1440) with multi‑touch – responsive and easy to read indoors and outdoors.Comprehensive Connectivity
Dual‑band Wi‑Fi (2.4/5GHz, 802.11 a/b/g/n)
Bluetooth 4.2
4G LTE global bands: FDD‑LTE (B1/3/5/7/8/20), TDD‑LTE (B38/40/41) + 2G/3G/CDMA fallback
Multi‑GNSS: GPS, BeiDou, GLONASS, Galileo
Professional Imaging & Feedback
Rear 13 MP autofocus camera with flash • Front 5 MP camera • Tri‑color breathing light • Motor vibration • Loudspeaker & microphone support voice calls.Physical Controls
Keys: Power, two SCAN buttons, Volume +/‑. Sensors include gravity, gyroscope, and proximity.
Key Technical Specifications (Complete)
| Category | Specification |
|---|---|
| Physical Parameter | |
| Size | 170 × 80(73) × 23 mm |
| Weight | <420g (including battery) |
| Display Screen | 5.5 inch IPS HD+ (720×1440), multi‑touch |
| Battery Capacity | 3.8V / 5000mAh, detachable |
| Interface | TYPE‑C USB 2.0 |
| Audio | Loudspeaker, microphone, voice call support |
| Camera | Front 5 MP; Rear 13 MP autofocus with flash |
| Notify | Tricolor breathing light, motor |
| Keys | Power button, SCAN button ×2, Volume +/‑ |
| Sensors | Gravity sensor, gyroscope sensor, proximity sensor |
| Performance Parameter | |
| CPU | Qualcomm SDM450 octa‑core 1.8 GHz |
| OS | Android 10.0 |
| RAM+ROM | 4GB + 64GB |
| Extra Memory | Expandable via TF, up to 128GB |
| Communication Transmission | |
| WLAN | Dual‑band Wi‑Fi (2.4/5GHz), 802.11 a/b/g/n |
| WWAN | 2G: GSM B5/3/8 3G: WCDMA B1/5/8; TD‑SCDMA B34/39; CDMA/EVDO BC0 4G: FDD‑LTE B1/3/5/7/8/20; TDD‑LTE B38/40/41 |
| Bluetooth | BT4.2 |
| GNSS | GPS / BeiDou / GLONASS / Galileo |
| Scanner | |
| Scanning Engine | Honeywell N6603 |
| Barcode Types | Code 128, Code 39, UPC/EAN, Code 93, Interleaved 2 of 5, PDF417, Data Matrix, QR Code, Aztec, MaxiCode, etc. |
| Scanning Accuracy | ≥3mil |
| Optional Function | |
| NFC | Frequency: 13.56MHz Protocol: ISO14443A/B, ISO15693, NFC Tag support: M1(S50, S70), CPU, NFC tags Read‑write distance: 2‑3cm |
| Environmental Parameter | |
| Operating Temperature | -10℃ to 50℃ |
| Storage Temperature | -40℃ to 70℃ |
| Environment Humidity | 5%RH – 95%RH (non‑condensing) |
| Accessories | |
| Standard Accessories | Power adapter ×1, USB data line ×1, Battery ×1, Protective film ×1, Manual ×1, Wrist strap ×1 |
Optimized for Your Industry
Warehouse & Logistics – Quickly scan barcodes from pallets, bins, and packages with the Honeywell N6603 engine.
Retail Management – Assist customers with price checks, inventory lookup, and NFC‑based loyalty or payments.
Field Service – Capture asset tags, take photos with the 13MP camera, and record GPS coordinates.
Inventory Counting – Reliable scanning even for small or damaged labels (≥3mil accuracy).
Why Honeywell N6603?
The Honeywell N6603 is a proven industrial 2D imager known for:
Aggressive decoding of poor quality or low‑contrast barcodes
Fast motion tolerance – ideal for conveyor belt or high‑volume scanning
Wide field of view and excellent depth of field
What’s in the Box
Standard accessories: Power adapter ×1, USB data cable ×1, Battery ×1, Protective film ×1, User manual ×1, Wrist strap ×1
Ready to Enhance Your Data Collection?
The RS60 handheld terminal delivers enterprise‑grade barcode scanning with the trusted Honeywell N6603 engine, plus a rugged design, long battery life, and optional NFC. Contact us for a demo, sample testing, or volume pricing.
