7.0-Inch High Bright IPS TFT-LCD Display RGB interface & CTP

This source-tracked comparison record covers a 7.0" IPS-TFT module. Its imagery and listed values support initial engineering review; availability, model ownership and the final specification require Fuzheng confirmation before quotation or sample evaluation.

IPS-TFT
Square
RGB
CTP / PCAP
800 (RGB) x 480

Screen Size: 7.0"
Resolution: 800 (RGB) x 480
Technology: IPS-TFT
Shape: Square
Interface: RGB
Touch: CTP / PCAP

Comparison candidate: availability, model ownership and all specifications require confirmation before quotation.

Exact-record review: Reference media and values remain attached to a clearly marked confirmation candidate.
Integration context: Format, interface, touch, optical and mechanical review points are organized around the published data.
Product-specific inquiry: Quotation, sample and WhatsApp actions carry this display name into the engineering discussion.

Product details

Review the module around published evidence.

The current record identifies 800 (RGB) x 480 resolution, RGB interface, CTP / PCAP touch information, 1000 cd/m2 brightness. Use these values to narrow the shortlist, then confirm the electrical, optical and mechanical requirements against the host product.

Square TFT modules for compact interfaces that need a balanced active area and a compact mechanical footprint. Final suitability depends on the approved drawing, sample evaluation and the host system requirements.

Product views

Inspect the module from the available source imagery.

Images stay contained and uncropped so the display, flex cable, connector and visible assembly details remain available for review.

Published product data

Specifications in one consistent format.

Reference values are displayed for comparison and require confirmation before quotation.

Published specifications for 7.0-Inch High Bright IPS TFT-LCD Display RGB interface & CTP
Specification	Published value	Review status
Screen Size	7.0"	Confirm before quotation
Resolution	800 (RGB) x 480	Confirm before quotation
Technology	IPS-TFT	Confirm before quotation
Shape	Square	Confirm before quotation
Interface	RGB	Confirm before quotation
Touch	CTP / PCAP	Multiple source values — confirm
Brightness	1000 cd/m2	Confirm before quotation
Viewing Angle	All round - IPS	Confirm before quotation
Module Dimensions	182.6 x 117.8 x 8.58mm	Confirm before quotation
Aspect Ratio	5:3	Confirm before quotation

Design-in review

Move from a catalog match to a controlled sample evaluation.

Format and image area

Published screen size: 7.0". Resolution: 800 (RGB) x 480. Shape: Square. Module dimensions: 182.6 x 117.8 x 8.58mm.

Electrical connection

Published interface: RGB.

Optical and front assembly

Published touch information: CTP / PCAP. Brightness: 1000 cd/m2. Viewing angle: All round - IPS.

Configuration discussion

Define the requirements that the catalog record cannot decide alone.

Use the published values as a starting point, then document the host electronics, enclosure, user interface and operating environment before requesting a sample.

Send product requirements

Confirm availability and the final electrical, optical and mechanical specification before design-in.
Review interface, connector and FPC alignment against the host electronics.
Discuss touch panel and cover lens requirements where the product design needs a front assembly.
Confirm outline, active area, mounting constraints and environmental requirements before sample approval.

Product FAQ

Planning the next engineering step.

Answers stay within the published record and the information needed for a useful RFQ.

Which product details should be confirmed before design-in?

Confirm availability, product ownership and every electrical, optical and mechanical value with Fuzheng before quotation, schematic release or sample evaluation.

What should I include in an inquiry for this display?

Include the product name or model, target size and resolution, host interface, touch and cover-lens requirements, brightness and environment, quantity and current project stage.

Can I request a sample for evaluation?

Use the sample request action and share the intended electrical and mechanical integration requirements so the evaluation scope can be discussed around this exact record.

Can interface, touch or mechanical requirements be discussed?

Yes. Send the host interface, connector or FPC constraints, touch and cover-lens needs, outline limits and environmental targets for an engineering review. No unpublished capability is assumed on this page.
