Model no.FZ128001S24

1.28-Inch 240x240 Round IPS TFT-LCD Display Module

FZ128001S24 is a 1.28-inch round IPS TFT-LCD display module with 240x240 resolution, SPI interface, 24-pin connection, 420 cd/m² brightness and GC9A01 driver IC.

IPS TFT-LCD
Circular
SPI
1.28-inch circular display
IPS wide viewing angle
240 x 240 resolution
SPI interface
24-pin connection

Screen Size: 1.28 inch
Resolution: 240 × 240
Technology: IPS TFT
Interface: SPI
Viewing Angle: IPS wide viewing angle

Review the listed module configuration and confirm the matching specification and drawing revision with your inquiry.

Product overview

The FZ128001S24 is a compact 1.28-inch circular IPS TFT-LCD module for embedded interfaces where a round active area fits the product enclosure. Its current product record publishes a 240x240 pixel matrix, SPI host interface, 24-pin connection and GC9A01 driver IC.

The 35.6 × 38.1 × 1.55 mm module has a Ø32.4 mm active area and 420 cd/m² published brightness. It is supplied without a capacitive touch panel by default; touch, cover glass, FPC, backlight and wide-temperature requirements can be reviewed as project-specific customization items.

Confirm the FZ128001S24 assembly against the latest specification and drawing revision before design-in.

Product highlights

1.28-inch circular display
IPS wide viewing angle
240 x 240 resolution
SPI interface
24-pin connection
GC9A01 driver IC

Technical specifications

Values are normalized from the current product record; no missing parameter is estimated.

Published specifications for 1.28-Inch 240x240 Round IPS TFT-LCD Display Module
Specification	Published value
Screen Size	1.28 inch
Resolution	240 x 240
Technology	IPS TFT-LCD
Shape	Circular
Interface	SPI
Brightness	420 cd/m²
Viewing Angle	IPS wide viewing angle
Driver IC	GC9A01
Module Dimensions	35.6 (H) × 38.1 (V) × 1.55 (D) mm
Active Area	Ø32.4 mm
Pin Count	24

Mechanical fit

Screen Size: 1.28 inch
Shape: Circular
Module Dimensions: 35.6 (H) × 38.1 (V) × 1.55 (D) mm
Active Area: Ø32.4 mm

Allow space for the FPC, connector, cover lens and mounting. Use an approved, version-matched drawing before fixing the enclosure.

Review drawing availability →

Interface & integration

Connection information for FZ128001S24
Parameter	Source value
Interface	SPI
Driver IC	GC9A01

Confirm pin numbering, supply levels, controller revision and initialization before connecting power. Source tables are references, not a substitute for an approved electrical specification.

Format and image area

Published screen size: 1.28 inch. Resolution: 240 x 240. Shape: Circular. Module dimensions: 35.6 (H) × 38.1 (V) × 1.55 (D) mm. Active area: Ø32.4 mm.

Electrical connection

Published interface: SPI. Driver IC: GC9A01.

Optical and front assembly

Brightness: 420 cd/m². Viewing angle: IPS wide viewing angle.

Drawings & technical documents

Reference files from this product record, retained at their available source resolution.

Request the matching mechanical drawing

No separate mechanical drawing is verified in this record. Send your enclosure limits and the selected product reference; request the approved outline and FPC drawing before tooling.

Request drawing & datasheet

Match the module to your application

Use the published values as a starting point, then document the host electronics, enclosure, user interface and operating environment before requesting a sample.

Published application directions

Smart watches and wearable devices
Circular gauges and meter interfaces
Round HMI panels for home appliances
Industrial control interfaces
IoT device displays

Evaluation directions, not certification or completed customer-project claims.

Send product requirements

Discuss capacitive or resistive touch integration where the product requires touch input.
Review cover glass, FPC, backlight and wide-temperature requirements against the target enclosure and operating environment.
Review interface, connector and FPC alignment against the host electronics.
Discuss touch panel and cover lens requirements where the product design needs a front assembly.
Confirm outline, active area, mounting constraints and environmental requirements before sample approval.

Product questions

Specifications, documents and sample planning for FZ128001S24.

What are the published specifications for FZ128001S24?

FZ128001S24 currently publishes Screen Size: 1.28 inch; Resolution: 240 × 240; Technology: IPS TFT; Interface: SPI; Viewing Angle: IPS wide viewing angle. Confirm the final drawing and pin assignment against the supplied sample before design-in.

What should I include in an inquiry for this display?

Include the product name or model, target size and resolution, host interface, touch and cover-lens requirements, brightness and environment, quantity and current project stage.

Can I request a sample for evaluation?

Use the sample request action and share the intended electrical and mechanical integration requirements so the evaluation scope can be discussed around this exact record.

Can interface, touch or mechanical requirements be discussed?

Yes. Send the host interface, connector or FPC constraints, touch and cover-lens needs, outline limits and environmental targets for an engineering review. No unpublished capability is assumed on this page.

Discuss this display with our team

FZ128001S24

Share the required interface, touch assembly, quantity and project timing. Pricing and availability are confirmed by inquiry.

Start a product inquiry →
